Capacity: 2200kgs

1. CE Certification
2. Capacity: 4400 LBS
3. Fork Size: 27"W x 45"L
4. lowered height: 3.2" and raised height: 7.7"
5. Electric Move, Electric Lift,with Charger and Battery
6. Brushless Motor
7. Automatic parking brake withelectromagnetic brake

Product Description

What are the functions of Electric Pallet Truck?
Ideal for handling bulky heavy materials. Such as, Loading、Unloading、Picking and Transportation etc.
Why option us?
1) Reliability
·   CE certification
·   Heavy-duty design
2)  Efficiency
·    Unique electric lifting system offers easy operation and lifting.
·    Longer service time by Brushless Motor 48V/30 Ah.( 4 hours fully charged,appr.7 hours used )
·    Turning Radius 58" and round fork tips& tail can be easyused at narrow space.
3)  Ergonomic design
·        Multi-function controller handle with speed control button, slowspeed button, lifting/lowering switch, alarm etc.

4)  Safety and EasyMaintenance
·    Emergency button and anti-collision button ensure the safety ofoperator.
·   Block design, More Easy operate and service.
Warning
·   Unauthorized maintenance or training is strictly prohibited.

Product Information

Technical Details

Load Capacity	LBS	4400
Load center	Inch	24
Operating type	Walkie
Max. lifting height	Inch	4.5
Fork Length	Inch	45
Fork Overall Width	Inch	22/27
Driving Wheel Size	Inch	8.3/2.8
Bearing Wheel Size	Inch	3/2.4
Travel speed(laden/unladen)	km/h	4/4.5
Lift Speed(laden/unladen)	mm/s	59/39
Gradeability(laden/unladen)	%	6/16
Drive motor	KW	DC 0.65
Lift motor	KW	DC0.84
Battery voltage/capacity		48V/30Ah
